13. Functions recap
Code Description
101 Backlight 0 or 1
102 Display contrast control from 0 to 10
103 Sending data via Rs232 0 or 1
104 Keypad locking 0 or 1
105 Serial number display
Available settings
F100
Code Description
200
201 Unit of channel 2
Available settings
Unit of channel 1
F200
CP201 and 202 CP203 and 204 TH200 CTV210
00 Inactive channel Inactive channel Inactive channel
01 Pa mbar °C m/s
02 mmH O inWg °F fpm
2
03 inWg KPa %RH °C
04 mbar PSI g/Kg (absolute humid. °F
3
05 mmHg mmHg °C (dew temp. Td) m /h
06 m/s m/s °F (dew temp. Td) L/s
07 fpm fpm °C (humid temp. Tw) cfm
3 3 3
08 m /h m /h °F (humid temp. Tw) m /s
09 L/s L/s KJ/Kg (Enthalpy i)
10 cfm cfm
3 3
11 m /s m /s
Inactive channel
ñ)
Code Description
300 0=>0V, 1=>5V, 2=>10V
3=>4mA, 4=>12mA, 5=>20mA
301 Analogue output minimum on channel 1
302 Analogue output maximum on channel 1
303 Analogue output setting on channel 2 0=>0V, 1=>5V, 2=>10V
3=>4mA, 4=>12mA, 5=>20mA
304 Analogue output minimum on channel 2
305 Analogue output maximum on channel 2
306 Activation / Deactivation of purge mode 00 or 01
307 Working time of each purge from 01 to 60 seconds
308 Frequency of each purge from 01 to 9999 minutes
309 Time-delay before and after purge from 00 to 60 seconds
Available settings
Analogue output setting on channel 1
F300
channel 2
c h a n n e l 1
CP 200
Page 31
Class 200 transmitter configuration via keypad
