Kimo Class 200 User Manual

6.f - Alarm mode selection
6. Alarm / relay settings
F400
Page 15
1
> F 100
Step
Go into configuration mode (see page 2). The folder number displayed
corresponds to the last configuration folder used.
2
> F 400
Step
Select the folder “400” and validate with .
02
3
F 403
Step
>
4
Step
With and keys, select the code relative to the alarm mode (see chart
below). Validate with .
02
F 403
>
02
5
F 403
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder
400.
>
Alarm 1 Alarm 2 Relay 1 Relay 2
Mode “403” “408” “413” “418”
Select sub-folder
and validate with .
Code Alarm mode Drawing
00 No alarm
01 N° 1 page 13
02 1 setpoint with time-delay and rising action N° 2 page 14
03 1 setpoint with time-delay and falling action N° 3 page 14
2 setpoints with time-delay (control mode)
Class 200 transmitter configuration via keypad
