Kimo Class 200 User Manual

3. Display and keypad configuration
Page 3
F100
3.b - Display contrast control
1
> F 100
Step
Go into configuration mode (see page 2). The folder number which appears
corresponds to the last configuration folder used.
2
> F 100
Step
Select the folder “100” and validate with .
05
3
F 102
Step
Select the sub-folder “102” and validate with .
The cursor > goes to the line of available choices.
>
4
Step
With and keys, set the contrast required (from 0 to 10). Validate with .
08
F 102
>
08
5
F 102
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from folder 100.
>
3.a - Backlight
With the backlight, the reading is easier with more contrast, if the ambient light is weak.
You can activate or deactivate it.
1
> F 100
Step
Go into the configuration mode (see page 2). The folder number displayed
corresponds to the last folder used.
2
> F 100
Step
Select the folder “100” and validate with .
01
3
F 101
Step
Select the sub-folfer “101” and validate with .
The cursor > goes to the line of available choices.
>
4
Step
With and keys, select 00 to deactivate the backlit or 01 to activate.
Validate with .
01
F 101
>
01
5
F 101
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to select another folder.
• with and keys, you can choose another sub-folder from the folder
100
>
Class 200 transmitter configuration via keypad
