6.g - Setpoints and time-delay setting
6. Alarm / relay settings
F400
Page 16
1
> F 100
Step
Go into configuration mode (see page 2). The folder number displayed
corresponds to the last configuration folder used.
2
> F 400
Step
Select the folder “400” and validate with .
02
3
F 404
Step
>
4
Step
With and keys, select the value sign: negative or positive. Validate with
.
Then, enter the setpoint value and validate with .
-00100
F 404
>
-100
5
F 404
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder
400.
>
Alarm 1 Alarm 2 Relay 1 Relay 2
Setpoint 2 “405” “410” “415” “420”
Setpoint 1 “404” “409” “414” “419”
Select sub-folder
and validate with .
6.g.1 - Setpoints
!
You must enter values according to the units of measurement selected, not
according to the measuring range of the transmitter.
Ex. on a CP 201 pressure transmitter (0 to ±1000 Pa) with a reading in mmH2O, the minimum and maximum ranges must be
configured on measuring range of 0 to ±102 mmH2O. See conversion chart on page 9.
If after having set up a setpoint, the unit of measurement is modified (see page 5), then you have to reconfigure
the setpoints according to this new unit of measurement.
To configure the setpoint 2 (alarm in control mode, see p13),
select sub-folder
Class 200 transmitter configuration via keypad
