10. Airflow measurement configuration
F600
Page 24
4
Step
With and keys, enter the value (from 0 to 3000mm or 0 to 118.11 inch).
Validate with .
>
1500
F 607
1500
5
F 607
Step
The cursor > returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 600.
>
If you enter a length, width or diameter in mm, the transmitter will automatically calculate the conversion in Inch
(in sub-folder “601”) and vice versa
10.a.2 - Working from a airflow coefficient
With this coefficient, you can calculate the airflow from the pressure. This coefficient is given by the manufacturer of the
devices supplied with pressure connections (+ and -). From the square root of the pressure measured (Delta P),and from this
coefficient, you get the airflow.
Airflow = C x Pressure
D
1
> F 100
Step
Go into configuration mode (see page 2). The folder number displayed
corresponds to the last configuration folder used.
2
> F 600
Step
Select the folder “600” and validate with .
40.25
3
F 613
Step
Select the sub-folder “613” and validate with .
The cursor > goes to available choices.
>
4
Step
With and keys, enter the airflow coefficient value (from 0.1 to 9999.9).
Validate with .
>
01
5
F 614
Step
The cursor > returns to sub-folders line.
Select the sub-folder “614” to select the unit of measurement in pressure for
the airflow calculation and validate with .
The cursor > returns to available choices.
>
40.25
F 613
!
Function only available for the pressure transmitter: CP 200 + SQR option. In this calculation mode, you
have no access to reading of air velocity. If you activate this calculation mode and also a channel in
air velocity, the transmitter will display an error code “4”.
Go back to procedure page 23 / step 3:
With and keys, select 02 and validate with .
!
Class 200 transmitter configuration via keypad
