Kimo Class 200 - Page 37

13. Functions recap
Code Product Description
500 CP200 from 0 to 9
500 TH200 Offset in humidity -50,0 to +50,0
501 TH200 Offset in temperature (°C) from -50,0 to +50,0
502 TH200 Offset in temperature (°F) from -90,0 to +90,0
Available settings
Measurement integration
F500
Code Description
600 -
601 Compensation temperature in °F* -
603 Air velocity measurement mean*
604 Air velocity coefficient value* from 0,0001 to 9,9999
605 Air velocity correction coefficient from 0,200 to 2,000
606 Section type selection
607 Section length in mm from 0 to 3000 mm
608 Section width in mm from 0 to 3000 mm
609 Section diameter in mm from 0 to 3000 mm
610 Section length in inch from 0 to 118.11 inch
611 Section width in inch from 0 to 118.11 inch
612 Section diameter in inch from 0 to 118,.1 inch
613 Airflow coefficient* from 0.1 to 9999.9
614 Units of pressure
for the pressure calculation*
Available settings
Compensation temperature in °C*
F600
Code Differential probe
00 Pitot tube
01 DEBIMO blade
02 Other differential probe
Code Section type
00 Rectangular
01 Circular
02 Airflow coefficient
CP201 and 202 CP203 and 204
01 Pa mbar
02 mmH O inWg
2
03 inWg KPa
04 mbar PSI
05 mmHg mmHg
Page 33
Class 200 transmitter configuration via keypad
CP 200 - CTV 210
