5.14.2 Battery Indicator Setting
VOL indicates the battery indicator setting. It is required to input the voltage values
of 1 to 5 one by one. Take the first battery value as an example: “1” on the display
indicates the first voltage and “31.5” is the first battery value. Change the value by
increasing/decreasing with UP/DOWN. Press MODE to confirm and enter the next
battery value setting. After the 5 power values are set, press MODE to confirm and
return to the personalized parameter setting interface.
Battery indicator setting
5.14.3 PAS Parameter Setting
5.14.3.1PAS Level Selection
SCA indicates the PAS parameter setting. Eight modes are provided for selection:
0-3, 1-3, 0-5, 1-5, 0-7, 1-7, 0-9, 1-9. Switch by UP/DOWN, press MODE to confirm,
and enter the corresponding PAS ratio value setting interface.
