Pas level selection
5.14.3.2 PAS Proportion Setting
By setting the PAS proportion, you can adjust the speed of each assist level to
meet the needs of different riders. Taking the first level as an example, “30 - 50” is
the recommended range of the PAS proportion, and “40” is the current value of the
first level (i.e. the output is 40%). By increase/decrease settings with UP/ DOWN.
Press MODE to confirm and enter the next PAS proportion setting. After the
setting finished, press MODE to confirm and return to the personalized parameter
setting interface. Refer to table 4 for details.
PAS proportion setting
5.14.4 Current Limit Setting
CU indicates the current limit setting. The current limit can be set from 7.0-18.0A.
