KING-METER TECHNOLOGY CO., LTD
No.15, Chenchang Road, Beichen Dist.Tianjin,300134, CN
Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378
The walk assist function can only be used when the user pushes the
electric vehicle, please do not use it in the riding state.
5.6Turn On Backlight
Hold UP for 2 seconds to turn on the backlight of display, and at the same
time notify the controller to turn on the front light. When the external light is
insufficient or when driving at night, the rider can turn on LCD backlight. Hold UP
button again for 2 seconds, the LCD backlight turns off.
Backlight and light display
5.7 PAS Level Selection
Press UP or DOWN to adjust the PAS levels and change output power of the
motor. The default level range is 1-5, and default level when the display is turned
on is 1.
