KING-METER TECHNOLOGY CO., LTD
No.15, Chenchang Road, Beichen Dist.Tianjin,300134,CN
Fax：+0086 022 8478 0358 Tel: +0086 022 8478 0378
10
5.7 PAS Level Selection
Short press the UP or DOWN button to switch the power gear of the Ebike and change the
output power of the motor. The default output power range of the display is 0-5, and the
default gear of the display is 1.
5.7 Battery Indicator
The 5 battery bars represent the capacity of the battery. When the battery is in low voltage,
battery frame will flash to notice that the battery needs to be recharged immediately.
Low Voltage Flash
5.8 Motor Power Monitor
The display can show the output power of the current motor.The display mode is shown in the
following figure.
To Next Page
