The Sensitivity of PAS Setting
SCN means the sensitivity of PAS, and 2 to 9 can be selected.2 is strongest, 9 is the weakest.
UP/DOWN is to select sensitivity value, and MODE is to confirm selection and turn to magnet
disk setting. SCN default value is 2.
Proportion parameters Setting of PAS
N - denotes the proportional parameter of the PAS sensor.The parameter value can be
selected through UP / DOWN.The larger the value, the more obvious the feeling of
assistance.Press and hold MODE to confirm and return to the display personalized parameter
setting interface.
8.5.6 Speed sensor settings
SPS means Speed Sensor. Press UP/DOWN to select the quantity of magnet head (the range
is from 1 to 9), and press MODE to confirm and turn to Throttle Definition page. SPS default
value is 1.
