8. User settings
8.1 Preparation before starting
Make sure that the connector is firmly connected and turn on the Ebike power.
8.2 General settings
Press MODE button to start the display, then hold both UP and DOWN for 2 seconds to enter
the setting menu.
8.2.1 Trip Distance Clearance
TC means trip distance clearance, and the setting parameter can be n / y.The default n means
that the trip of a single ride is not cleared.Y / N can be selected through UP / DOWN. Y means
that the trip of a single ride needs to be cleared, and N means that the trip of a single ride does
not need to be cleared.
8.2.2 Backlight brightness setting
BL stands for backlight. Setting parameter 1, 2 and 3 can be set to indicate backlight
brightness.The default value of the display from the factory is 1.The backlight brightness
To Next Page
