1. Appearance and Size
1.1 Material and color
SW-U products are made of PC. Under the temperature of -20 to 60℃, the shell material can
ensure normal usage and good mechanical performance.
Real product and dimension figure (unit: mm)
2 Function Summary and Button Definition
2.1 Function description
SW-U provides a wide range of functions and indicators to fit the users’ needs. The indicated
contents are as following.
◆Battery Indicator
◆Motor Power Ratio
◆Speed Display (including running speed, max speed and average speed)
◆Trip distance and total distance
◆Cruise control
◆Backlight On/Off
◆Error Code Indicator
