N3-button unit is connected to the bottom of the SW-U LCD display via lead cable.
In the following instructions, the key is named as “MODE” .The key is named as
"UP", and the key is named as "DOWN".
The shape of N3 button is as follows:
N3 key is connected with the bottom lead of SW-U-II display
In the following description, the key is named as "MODE".The key is named as "UP",
and the key is named as "DOWN".
