Kioti CS2610 User Manual

6
-
8
CS2610
DRAFT HITCH AND TRAILER
(1) Draw Bar
The draw bar is used to pull an imple-
ment, such as a trailer. This tractor is
equipped with a ne draw bar. Make
sure to check the max. towing weight
of the trailer and max. vertical load
that can be applied to the draw bar.
-
Max. trailer weight (trailer + loaded
weight) = 250 kg (551 lbs)
-Vertical load of hitch (draw-bar)
= 250 kg (551 lbs)
When using an implement that
is attached to the draw bar,
such as a trailer, check if the
towing hitch is rmly attached.
•
CAUTION
H11O104A
M55O117AM46O605A
C56O174A
M46-EU,AU-06.indd 8 2012-03-08 오후 7:02:53

Kioti CS2610 Specifications

General

Engine Power	24.5 hp
Engine Type	3-cylinder diesel
Transmission	Hydrostatic
Drive	4WD
Gears	Infinite (2-range)
Front tire size	18x8.5-10
PTO Speed	540 RPM
Hydraulic System Type	Open center
3-Point Hitch Category	Category 1
Fuel Capacity	6.6 gal
Rear tire size	26x12.0-12
Turning Radius	8.2 feet
