Kioti CS2610 User Manual

4
-
27
DESCRIPTION OF OPERATING SYSTEM
4
M46O453A
(1) Quick Coupler
An Auxiliary valve can be installed to
the tractor optional and a port can be
attached to front or rear way according
to option kit.
The auxiliary valve is installed to one
of 3/8" quick couplers.
AUXILIARY PORT (OPTIONAL) PTO SHAFT COVER & CAP
(1) P.T.O Shaft Cover (2) P.T.O Shaft Cap
Use only the double mounting full type
PTO cover.
The cover can be turned to the top to
facilitate implement installation on the
PTO spline shaft.
Make sure to install the PTO cap when
the PTO is not in use.
M46O449A
(1) Cup Holder
The cup holder is installed to the left
fender for driver's convenience.
ACCESSORY SYSTEM
CUP HOLDER
M46O441A
M46-EU,AU-04.indd 27 2012-01-19 오후 1:48:55

Kioti CS2610 Specifications

General

Brand	Kioti
Model	CS2610
Category	Tractor
Language	English
