4
-
11
DESCRIPTION OF OPERATING SYSTEM
4
TACHOMETER/HOUR METER
INDICATOR
(1) Tachometer
(2) Hour Meter Indicator
(3) Rated Engine Speed
M46O411A
M46O412A
(1) Fuel Gauge
“E” : Empty “F” : Full
FUEL GAUGE
This indicates the remaining fuel
level after the key switch is turned to
the “ON” position.
F : Fuel is fully lled.
E : Replenish the fuel tank.
If driving is continued with the needle
below the position “E”, air may enter
the fuel supply system. In this case,
bleed the system. (For detailed
instructions, refer to Bleeding fuel
system” in the chapter “Service”)
It indicates the engine rpm that can
drive 540 rpm of P.T.O speed. For
speedy and effective work, adjust the
work load so that the engine rpm is
close to this mark "
".
The hour meter does not operate if
the engine is stopped even though
the key switch is in the "ON" position.
Make sure to use only correct
fuel as the engine can be dam-
aged if unqualied fuel is used.
Use fuel for winter season in
cold weather to start the engine
easier.
The gauge needle can move on
a hill or curve as fuel slopes in
the tank.
NOTE
M46-EU,AU-04.indd 11 2012-01-19 오후 1:48:27
