Kioti CS2610 User Manual

3
SPECIFICATIONS
3
-
5
moDel cs2610 remarKs
Hyd.sys
Max. lifting capacity
kg (lbs.)
61cm (24in.) Behind 318 (700)
Lower link end
715 (1,580)
P.T.O
Rear
Type Independent
P.T.O shaft
1- 3/8” 6 splines
Speed
(P.T.O rpm/engine rpm)
540/3,000
Mid (optional)
P.T.O shaft (*)
16/32” 15 splines
Speed
(P.T.O rpm@engine rpm)
2,000@3,000
Min. turning radius
(with one rear wheel braked) m (feet)
0.77 (2.54)
Weight (with ROPS)
kg (lbs.) 660 (1,455)
Max. Drawbar vertical load
kg (lbs.) 250 (551)
Max. Trailer loading weight
kg (lbs.) 250 (551)
(*):
In compliance with A.S.A.E. standards
M46-EU,AU-03.indd 5 2012-01-18 오후 6:34:18

Kioti CS2610 Specifications

General

Engine Power	24.5 hp
Engine Type	3-cylinder diesel
Transmission	Hydrostatic
Drive	4WD
Gears	Infinite (2-range)
Front tire size	18x8.5-10
PTO Speed	540 RPM
Hydraulic System Type	Open center
3-Point Hitch Category	Category 1
Fuel Capacity	6.6 gal
Rear tire size	26x12.0-12
Turning Radius	8.2 feet
