USING THE STAND MIXER | 19
USING THE STAND MIXER
OPTIONAL ATTACHMENTS
KitchenAid offers a wide range of optional attachments such as food grinders or
pasta makers. They may be attached to the Stand Mixer attachment power shaft,
as shown here.
1
To attach: Turn speed control
to “0”. Unplug Stand Mixer.
2
Loosen attachment knob by turning
it counterclockwise. Remove
attachment hub cover.
3
Insert attachment shaft housing into
attachment hub, making certain that
attachment power shaft fits into
square attachment hub socket. It may
be necessary to rotate attachment
back and forth. When attachment
is in proper position, the pin on the
attachment will fit into the notch
on the hub rim.
4
Tighten attachment knob by turning
clockwise until attachment is
completely secured to Stand Mixer.
