2-6
INSTALL OVEN
Excessive Weight Hazard
Use two or more people to move and
install oven.
Failure to do so can result in back or
other injury.
WARNING
1. Using 2 or more people, lift oven partially
into cabinet cutout using the oven opening
as an area to grip.
N
OTE: Push against seal area of oven front
frame when pushing oven into cabinet. Do
not push against outside edges.
2. Push against seal area of front frame to
push oven into cabinet.
3. Push oven completely into cabinet and
center oven into cabinet cutout.
3-Wire Cable from Home Power Supply
- U.S. Only
IMPORTANT: Use the 3-wire cable from home
power supply where local codes permit a 3-wire
connection.
A. Cable from home power supply
B. Junction box
C
. Black wires
D
. White wires
E
. Gre
en (or bare) ground wire
(from
oven)
F. 4-wire flexible c
able from
oven
G. Red wires
H
. UL listed wire connectors
I. U
L listed or CSA approved
conduit connector
B
C
D
E
F
H
G
A
I
1. Connect the 2 black wires (C) together
using a UL listed wire connector.
2. Connect the 2 white wires (D) and the green
(or bare) ground wire (of the oven cable)
using a UL listed wire connector.
3. Connect the 2 red wires (G) together using
a UL listed wire connector.
4. Install junction box cover.
