4-29
9. To remove the latch motor, remove the
two motor screws from the bottom of the
assembly.
10. To remove the door or latch switch,
remove the bracket screw. NOTE: You will
have to remove the latch motor (in step 9) to
access the door or latch switch screws.
Latch Motor Screws
Latch Switch Screw
REASSEMBLY NOTE: After you reinstall the
door latch assembly in the oven, press the two
covers back down into place. Use a piece of
shipping tape and tape over the front edge of
the top cover to hold it in place and keep it from
vibrating during operation.
Door Switch Screw
