6-3
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
FAILURE
(Leftmost
2 Clock
Digits)
ERROR
(Rightmost
2 Clock
Digits)
MESSAGE/DESCRIPTION
SUGGESTED CORRECTIVE ACTION PROCEDURE
F0
Default
E0
No failure (GOOD)
F1
Component
E0
CHECK OVEN USER INTERFACE
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect power.
B
. Replace oven user interface board.
C
. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Go to step 1 and complete checks.
F1
Component
E1
CHECK OVEN APPLIANCE MANAGER
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect power.
B
. Check oven door switch. If OK, go to step C.
C
. Replace oven appliance manager.
D
. Replace all parts and panels before operating.
E
. Plug in oven or reconnect power.
F
. Verify operation is normal. Press OFF, OFF, START
to reenter the Diagnostic
Mode and complete
checks.
F1
Component
E2
CHECK MICROWAVE USER INTERFACE
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect power.
B
. Replace microwave user interface.
C
. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Press OFF, OFF, START
to reenter the Diagnostic
Mode and complete
checks.
F1
Component
E3
CHECK MICROWAVE APPLIANCE MANAGER
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect power.
B
. Replace microwave appliance
manager.
C. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Press OFF, OFF, START
to reenter the Diagnostic
Mode and complete
checks.
FAILURE
(Leftmost
2 Clock
Digits)
ERROR
(Rightmost
2 Clock
Digits)
MESSAGE/DESCRIPTION
SUGGESTED CORRECTIVE ACTION PROCEDURE
F1
Component
E4
CHECK MICROWAVE POWER RELAY
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect
power.
B. Replace microwave power relay.
C
. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Press OFF, OFF, START to reenter the Diagnostic
Mode and complete checks.
F1
Component
E5
CHECK MICROWAVE INVERTER
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect
power.
B. Replace microwave inverter.
C
. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Press OFF, OFF, START to reenter the Diagnostic
Mode and complete checks.
F1
Component
E6
CHECK MICROWAVE WAVE GUIDE
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. U nplug oven or disconnect power.
B
. Replace microwave wave guide.
C
. Replace all parts and panels before operating.
D
. Plug in oven or reconnect p
ower.
E. Verify operation is normal. Press OFF, OFF, START to reenter the Diagnostic
Mode and complete checks.
F2
Keypad
E0
E1
KEYPAD DISCONNECTED
STUCK OR SHORTED
KEY
PROCEDURE:
Before proceeding, press OFF, OFF, START to enter the
Diagnostic mode.
A
. Unplug oven or disconnect
power.
B. Check keypad connector
for firm connection.
C. Replace all parts and panels before operating.
D
. Plug in oven or reconnect power.
E
. If error code returns after 60 seconds proceed to step F.
F
. Unplug oven or disconnect
power.
G. Replace keypad.
To Next Page
