41
(10) Install the chain bucket to the main body.
•
For information on how to install various types of buckets, refer to ER2 Series Electric Chain Hoist Owner's Manual (separate
document).
Cable Packing
Connector Socket holder
Holder A
Holder A
Holder C (upper side)
Holder C (lower side)
1
2
(9) Connect the power supply cable (upper
side) and the push button cord (lower side)
to Holder C, and then turn Holder A to
connect it.
•
For details, refer to ER2 Series Electric Chain Hoist
Owner's Manual (separate document).
Reassembly procedure
(To be continued)
Assembling the controller cover
To Next Page
