KLR 950 - Assembling the Clips Holder

KLR.950 Revision: 2023-10-06
Serial numbers: 3008 – beyond
KLR.00001 – beyond
9
4.3: Assembling the clips holder
The clips holder is attached with these threaded 1/4-20 holes:
To install it, it is needed:
 Two (2) PM-00278;
 Two (2) 1/4-20 socket head 2 ¼ inches long;
 Two (2) 1/4 washer;
 Two (2) 1/4 lock washer;
 Clips holder.
Final result:
