KLR.950 Revision: 2023-10-06
Serial numbers: 3008 – beyond
KLR.00001 – beyond
7
3.0: PRODUCT SPECIFICATION
3.1: Range of applications intended use and general functions
The bag closer KLR.950 is designed to close bag tail with plastic clip. The machine tells the user
whenever clip is running out. These following values are in the prototype version and are subject to
change:
Speed in between 50 and 60 package a minute.
Uses a convenient touch screen (HMI).
Uses a recipe and ingredient method, can be finetuned according to the product easily.
A KLR 930 Air printer or an ink jet printer can be installed on the equipment.
Made of stainless steel 304 and anodize aluminum.
Equipped with an Ethernet communication device.
Easy clip loading and does print automatically when loading (if set in the parameters).
Ambidextrous machine (left or right).
3.2: Dimensions (for transport)
The clips holder can be disassembled from the body of the machine to save space.
Height: 24 inches; Length: 16 inches; Width: 15 inches
3.3: Specification for electricity and air
This machine is intended to use these 4 possible specifications:
Electrical need: Access within 5 feet from the machine
120 Volts – 5 Amps – 1 Phase – 50 / 60 Hertz
220 Volts – 5 Amps – 1 Phase – 50 / 60 Hertz
Need a 3 pins female jack power cord adapter 18AWG. Provided in the packaging with the machine:
120v = PE-01531-15-5P-6 220v = Contact service for part number
In case of loss, order from KLR to get a new one and be sure to have the cord as per requirement for
your machine.
Pneumatic need: None. Air printer is sold separately (see air printer manual if needed)
