KLR 950 - 2: Interlock to Bagger Wiring

KLR.950 Revision: 2023-10-06
Serial numbers: 3008 – beyond
KLR.00001 – beyond
25
5.7.2: Interlock to bagger wiring
 ONLY qualified technician can perform this kind of task. A wrong wiring can result
in a breakage of the bagger controller or other components. For any questions, call
KLR for advices.
Pin out of the bag closing machine
The bag closer KLR.950 has a built in 5 pins plug intended to communicate to the bagger. This feature
allows the bagger to constantly communicate a certain speed to the bag closer to follow. The following
picture show the wiring of the connector. See "Configure interlock" for more info.
Female connector
Cable to bagger
Male connector bag
closer
(Already installed)
Signal 24vdc
0v
Encoder pulses 0v
Common 24vdc
WHITE
WHITE
BROWN
GREY
BLACK
BLUE
BROWN
GREY
BLACK
BLUE
X02
X01
XCOM
X02
X01
XCOM
PNP WIRING
NPN WIRING
Bagger encoder
Bagger running
Common
Common
Bagger running
Bagger encoder
Built
-
in 5 pins plug (male)
Dry contact
Signal 0v
Dry contact
Dry contact
Dry contact
Encoder pulses 24vdc
4
4
1 2
2
1
3
3 3
3
2
2
1
1
4
4
5
5
5
5
11
11
14
14
