KLR 950 - Spare Parts List KLR.950 SHEAR (LEFT and RIGHT)

KLR.950 Revision: 2023-10-06
Serial numbers: 2218 - Beyond
58
8.3: Spare parts list KLR.950 SHEAR (LEFT AND RIGHT)
Suggested spare part list per machine for KLR.950 (Shear option)
Numbers
Part
numbers
Quantity
Descriptions
1
OS
-
054S
2
SPRING, OD 3/8’’, WIRE 0.041’’, 3 3/4’’ LG.
2
OS
-
045
2
SPRING
3
PE
-
0021
6
5
FUSE GLASS
3
AMP
S
4
PE
-
00223
5
FUSE GLASS 2 AMP
S
5
PE
-
015
14
-
ASS
1
SINGLE AXIS MOTOR
WITH DRIVE 2.8A
6 PM-00275 1
JEWELERS HSS
SLOTING SAW, OD 2 1/2'', BORE
1/2'', .057'' THICKNESS
7
PM
-
01520
4
BEARING
8
P02
-
00095
8
BEARING
9
PR
-
95091
2
DRIVE PULLEY
10
PR
-
95059
2
IDLE WHEEL
11
PR
-
95116
2
PULLEY NUT
12
PR
-
95090
1
UPPER SPLINE DRIVE SHAFT
13
PE
-
01517
2
SENSOR OPTICAL 5MM
MOD SLOT TYPE
14
PR
-
95095
1
BAG
FINGER
15
PM
-
00269
1
PLASTIC RETRACT. PIN 1/2"
16
P02
-
00133
1
BEARING
17
PM
-
00350
-
16
6
FRONT TIMING BELT XL
18
PM
-
00350
-
18
6
REAR TIMING BELT XL
19
P02
-
00018
1
CAM FOLLOWER BEARING
20
PM
-
00277
1
FLEX SHAFT
COUPLER
21
PR
-
95156
1
PIN
22
OS
-
130
1
SPRING
23
PE
-
95001
1
STEPPER MOTOR WIRE
24
PR
-
95145
1
BELT BASE FOR SPRING STEEL
25
PR
-
95146
1
BELT BASE
2
6
PR
-
95147
1
BELT BASE
27
PR
-
95148
1
BELT BASE FOR SPRING STEEL
28
PE
-
95002
-
1
1
ENCODER WIRE
29
PR
-
95002
-
2
1
BAG SENSOR WIRE
30
PR
-
95143
1
SHEAR LEFT
31
PR
-
95016
1
SHEAR PLATE
