KLR 950 - 6: Replacing the Feeding Sensor

KLR.950 Revision: 2023-10-06
Serial numbers: 3008 – beyond
KLR.00001 – beyond
43
7. Dislodge the feeder shaft;
8. Remove the jewelry saw with a 3/4 wrench. Make sure the teeth will be oriented down as
shown;
9. Replace the saw and reassemble by following the reverse order.
6.2.6: Replacing the feeding sensor
Follow these steps:
1. Follow the procedure "feeder motors" step 1 to 3 before continuing;
2. Then replace the sensor using the same screw pattern;
3. Reassemble by following the reverse order, do not forget the reconnect the sensor.
