Secti on 3: Setting up routi ng
This section provides important guidelines for configuring a KMC BAC-5051E router for
BACnet routing. Review this information carefully for proper installation.
The BAC-5051E supports the following routing protocols.
l One MS/TP network
l One BACnet Ethernet
l Two IP networks that can be set up for any of the following protocols:
l Normal BACnet IP network routing
l BACnet broadcast management device with network and port address translation
l Foreign device registration with BACnet broadcast management devices (BBMD)
l PAD (packet assembling/disassembling) routing
Setting up routing can be performed either during initial configuration or after the router has
an IPaddress assigned and is installed in its permanent location. See Configuring the BAC-
5051E router on page 15 for initial configuration and log in procedures.
Topics in this section
BACnet IP routing 27
BACnet foreign device routing 28
BACnet Broadcast Management Device routing 30
BACnet PAD routing 32
BACnet Ethernet routing 33
MS/TP configuration 34
Router Core properties page 35
BACnet IP routing
Either of the two IP ports can be configured for normal IProuting. The values on this page
are assigned by the BACnet system engineer.
For the log in procedure, see the topic Initial setup on page 15.
1 Use an Internet browser to log in.
2 Click Routing and then Configuration.
3 Select Enable for one of the IP Ports.
4 Select Enable for the IP Port.
5 From the list box, choose IP (Normal).
BAC-5051E Router Section 3: Setting up routing
Revision J 27
