Status Icon Description Action
BBMD: Unknown
Indicates the router is
receiving BBMD traffic
from an unknown BBMD.
This does not stop traffic
from routing.
If appropriate, add the
unknown BBMD to the
local BDT. A possible
cause of unknown
traffic is an address
issue because of
network address
translation.
BBMD: Multiple
Indicates the router has
detected another BBMD
in the same subnet as
itself. Traffic is not
routed.
Remove a BBMD from
the network.
Foreign Device NAK
A foreign device is
preventing the router's
request to distribute
messages. Initially, this
will not block traffic.
However, as additional
registration requests are
received, attempts
speed up until traffic is
stopped.
The remote device
server cannot register
additional devices.
Increase the value of
Max FDT Entries in the
remote server or
register with a different
server.
Mismatched Network
Number
The learned network
does not match the
configured network.
Select Use Learned
Networks on the
Configuration page or
change the router's
network number.
Table 4–1 Route status conditions (continued)
Purging the Route Status list
To clear old data from the Route list, select a network and then click Purge.
l Choose Select to remove a specific remote network from the table.
l Choose Select Routes to remove all of the remote routes related to a directly
connected network.
The selected network or networks are then cleared from the list. As the router detects the
actual networks in use, they are added back to the list.
BAC-5051E Router Section 4: Diagnostics and status
Revision J 41
