KMC Controls BAC-5051E User Manual

Configure from a file
Configuration properties for the BAC-5051E router can be saved in a configuration file. The
configuration file can then be used as a backup file or to configure other routers with similar
properties.
1 Use an Internet browser to log in.
2 From the Advanced group, click Choose File.
3 Browse to the file location, choose the file, and then click Open.
4 When the Overwrite Router Configuration dialog opens, click OK to precede.
Choose File Browse to the location and choose the configuration file.
Save Configuration Saves the router configuration in the file config_5051E.json.
The file type is JSON (Java Script Object Notation) and it is saved in the Windows current
user's downloads folder.
Illustration 5–2 Configure from File page
Section 5: Advanced features KMC Controls, Inc.
54 Revision J

KMC Controls BAC-5051E Specifications

General

Brand	KMC Controls
Model	BAC-5051E
Category	Network Router
Language	English
