KMC Controls BAC-5051E User Manual

Section 1: Introduction
This section provides a description of the KMC Controls BAC-5051E router. It also
introduces safety information. Review this material before installing or operating the
router.
The KMC Controls BAC–5051E is a multi-port BACnet router. Router highlights are:
l Easy to install and simple to configure.
l Configured from internally served web pages.
l Internal network diagnostics and route status reports.
Topics in this section
Specifications 5
Accessories and replacement parts 7
Mounting the router 8
Connecting for network routing 8
Connecting power 9
Single-cable connection 11
Maintenance 12
If you encounter difficulty 12
Safety considerations 12
Using the router for a technician's service tool 13
Specifications
Specifications are subject to change without notice.
Communication ports
BACnet Ethernet and IP
10BaseT/100BaseT, RJ–45 connector
BACnet MS/TP
One optically isolated MS/TP port, 9.6–115.2kilobaud
Removable three-screw terminal block, 12–22 AWG wire
Switched end-of-line termination
USB
USB micro B connection for temporary power
Configuration and software
All configuration is through internal browser based configuration pages. Requires HTML5
browser.
BAC-5051E Router Section 1: Introduction
Revision J 5

KMC Controls BAC-5051E Specifications

General

Brand	KMC Controls
Model	BAC-5051E
Category	Network Router
Language	English
