KMC Controls BAC-5051E User Manual

Status Icon Description Action
Active The network is
functioning correctly and
capable of passing
traffic.
None required.
Busy The amount of network
traffic is high enough
that no new traffic can
be accepted.
A temporary condition
that does not require
intervention.
Down
Gone
The network is not
functional and is
rejecting traffic.
Most likely will require
manual intervention.
Conditions that cause
a network to be down
may include either LAN
or BACnet router
problems.
No Status
!
The router is searching
for the network.
Usually a temporary
condition. Does not
require intervention.
Duplicated Network
D
Two networks are using
the same network
number. A router cannot
pass traffic on a
duplicated network.
Usually requires
intervention to locate
and change the
duplicated network
number. Multiple
duplicated networks
are usually an
indication of a network
loop.
Duplicate MAC
M
The router has detected
two MS/TP device using
the same MAC address.
Traffic is not routed.
Change the MST/TP
MAC address in either
the router or the device
that contains the
duplicated number.
Sole Master
S
The router is not
detecting any master
MS/TP devices on the
local network. Slave
devices however, may
be present.
Requires corrective
action if master
devices are known to
be connected to the
local MS/TP network.
Table 4–1 Route status conditions
Section 4: Diagnostics and status KMC Controls, Inc.
40 Revision J
