SECTION 10
RECIRCULATION SYSTEM
Jan 2003
p. 10-4
05148424
Oil Filter
Replace filter element when the pressure reading is 1.4 bar (20psi) above
normal when at operating temperature. Maximum normal pressure is
1.7 bar (25psi).
Components: (1) Oil Filter Head
(2) Element
(3) Pressure Gage
Parts: Element
Tools: Filter Wrench
Rags
Container to collect oil spills
Replace Oil Filter
1. Unscrew element from filter head with the filter wrench.
2. Oil gasket of new element.
3. Screw new element on head.
4. Start pump and check for leaks.
