SECTION 12 PARTS LISTS

Figure 12-9 LOW PRESSURE WATER FILTER ASSEMBLY, 05126289

ITEM No. QTY. PART No. DESCRIPTION

1 1 05016381 Filter Body, with Air Bleed- off Valve

2 1 05127212 Valve, Relief, 50 – 150 psi

3 1 05105440 Gage, Pressure, O–100 psi, ¼” NPT, Bottom-Mount

4 2 10078152 Adapter, Bushing, ¾ x ½” - NPT, Brass

5 1 10078343 Adapter, Bushing, ½ x ¼” - NPT, Brass

6 2 10127801 Nipple, ½ NPT x 2.50-in., Brass

8 1 49870272 Cross, ½ - NPT, Brass

10 1 10073823 Tee, ½-NPT, Brass

11 2 05123666 Adapter, ½” NPT x –8 JIC, Straight, Brass

12 4 10173805 Barb, ½” ID Hose, -8 JIC Swivel, Brass

13 2 10114023 U-Bolt, 0.50, Stainless

14 1 10106722 Element, Filter, LP Water, Polypropylene, 10 Micron

15 1 10147460 Elbow, ½-NPT x –8JIC, Brass

16 1 95157418 Adapter, ½-NPT x –8JIC, Straight, Brass

17 1 05016514 Elbow, 90 deg, ½-NPT x –8JIC

p. 12-20

05139159
