KMT Streamline SL-IV - Orifice Support Capacity

SECTION 11
SPECIFICATIONS
Jan 2003
p. 11-5
05130653
A positive index indicates a tendency to deposit calcium carbonate, the higher the
positive value, the higher the scale formation. A zero index corresponds to water
that is in equilibrium with respect to calcium carbonate.
Orifice Support Capacity
The SL-IV Waterjet Pump supplies high pressure (HP) water up to 3,800 bar
(55,000 psi). The following table shows size, ratings, and maximum quantity of
orifices that can be supported.
Rated power
kW(hp)
Pressure
Bar (Psi)
Flow
lpm (gpm)
Qty
Orifice Diameter
mm (inch)
1 0.20 (0.008)
1 0.17 (0.007)
1 0.15 (0.006)
2 0.12 (0.005)
11 (15) 3,800 (55,000) 1.2 (0.30)
3 0.10 (0.004)
1 0.28 (0.011)
2 0.17 (0.007)
22 (30) 3,800 (55,000) 2.5 (0.65)
4 0.12 (0.005)
1 0.35 (0.014)
2 0.28 (0.011)
4 0.17 (0.007)
37 (50) 3,800 (55,000) 3.8 (1.0)
8 0.12 (0.005)
