SECTION 3
OPERATION
July 2003
p 3-4
05132519
3.2.2 Operating Procedures
The lights on the operator’s console provide information.
The following pages show start, stop and fault recovery procedures.
START PROCEDURE
1. Pull EMERGENCY STOP (E-STOP) palmbutton.
2. Push CONTROL POWER ON button. CONTROL POWER ON button light
(WHITE) will be ON.
3. Push Green button – motor starts and after a delay pump starts.
CONTROL POWER ON light will be ON
RUN green light will be ON
STOP PROCEDURE
From the following conditions, follow the procedure below to stop the SL-IV
pump:
RUN light (6) ON (Green)
CONTROL POWER light (3) ON (White)
SL-IV Pump Running
Push STOP button, RUN light (Green) will go OFF
CONTROL POWER ON light (White) will stay ON
SL-IV Pump will stop
3.2.3 Remote Operation
The waterjet pump is equipped with a REMOTE/LOCAL switch (4). The switch
transfers control from the local panel (signified by symbol) to a remote
panel (signified by the symbol).
The following list of functions can be wired remotely, but only the START is
affected by the REMOTE/LOCAL switch.
• RUN (status light GREEN)
• Malfunction (status light RED)
• Start ()
• Stop ()
• Emergency stop
() Indicates that the remote function will not operate if the remote/local
switch is in the local position. With the switch in remote position, these same
two functions are disabled on the local panel.
