SECTION 11
SPECIFICATIONS
Jan 2003
p. 11-1
05130653
SECTION 11 SPECIFICATIONS
Specifications
Following are the specifications for the SL-IV 11kW(15hp) Waterjet Pump. Included
are the specifications for the equipment, torque, cutting water, cooling water, and the
maximum quantity of orifices that can be supported.
Equipment Specifications
SL-IV Waterjet Pump Size
11 (15) kW (hp)
Installation location
Indoors
-Air borne dust/contaminants Minimal
Ambient temperature
-Minimum storage 2(36)
°C(°F)
-Minimum operating 5(40)
°C(°F)
-Maximum operating 40(104)
°C(°F) (see note [1])
Maximum Relative Humidity (see note [2])
-At Maximum Operating Temp. 95%
Electrical (see note [3])
-Motor type TEFC (see note [4])
200/3/50 42
208/3/60 41
240/3/60 38
400/3/50 21
415/3/50 20
Voltage / Service Amps
480/3/60 19
Volts/Phase/Hertz/Amps
Sound Level 75.5 dB(A)
Controls
-Voltage 24 volts, DC
-Power Supply 5 amps, DC
-Safety shutdown switch settings
High oil temperature 62 (144)
°C (°F)
Low oil level 30(8) liters (gal).
Hydraulic System
-Oil tank capacity 53(14) liters (gal)
-Recommended oil type
Regular applications
Mobil, DTE Heavy Medium, # 021029
(# 05022702)
Food applications AMOCO #FG68EL (# 49835762)
-Hydraulic oil operation
Minimum temperature 15(60)
°C(°F)
Maximum temperature 65(150)
°C(°F)
Note [1]: Based on motor nameplate data, oil temperature must be maintained within
operating specifications.
[2]: When relative humidity is above 50%, frequently check oil in tank for water
content.
[3]: Not all motor voltages are readily available, check with factory for availability.
[4]: Totally enclosed fan cooled.
