Center Beam End Caps
Exploded End Cap for Center Beam Assembly Detail
(Partial and Full End Cap Shown)
Step 1
Partial Height
End Cap (B)
Step 2
#10 - 32 x ¼", Cup Point
Black Set Screw (C)
Step 1
Full Height End Cap (A)
Step 2
#10 - 32 x ¼",
Cup Point Black
Set Screw (C)
Center Beam
OR
