Kobalt NEXT GENERATION OF TOUGH TOOLS SM2507LW User Manual

41
kobalttools.com
I.D. Description Size Q’ty
083Y COMPRESSION SPRING 1
083Z CORD CLAMP 1
0CES COMPRESSION SPRING 1
0CKS SPRING WIRE 1
0DVJ BLADE WRENCH 1
0J3M HEX WRENCH 3 mm 1
0J4E FLAT WASHER φ6*13-1 2
0JZF HEX. SOC. SET SCREW M6*1.0-10 2
0JZN ARBOR BOLT M8*1.25-20 1
0K51 CR. RE. COUNT HD. SCREW M4*0.7-8 4
0KA1 CR.RE. PAN HD. TAPPING SCREW M3*24-6 1
0KB7 CR.RE. PAN HD. TAPPING SCREW M4*18-16 2
0KB8 CR.RE. PAN HD. TAPPING SCREW M4*18-20 4
0KB9 CR.RE. PAN HD. TAPPING SCREW M5*16-10 1
0KDN CR. RE. PAN HD. SCREW M5*0.8-25 1
0KDR CR. RE. PAN HD. SCREW M5*0.8-10 1
0KE0 CR. RE. PAN HD. SCREW M6*1.0-40 2
0KQW LOCK NUT M5*0.8 1
0KTS CABLE CLAMP 2
0KUW TERMINAL 2
0S2B CR.RE. PAN HD. TAPPING SCREW M6*1.0-25 2
23NF ARBOR COLLAR 2
23NX GUARD-CORD 1
250Z HEX.SOCKET HD.CAP SCREWS M5*0.8-35 3
27PF COMPRESSION SPRING 1
2BLK COLLAR 1
2DUY LEAD WIRE ASS’Y 1
2E35 TRIGGER 1
2EYT POWER CABLE 1
2M0S LIMIT SWITCH 1
2MDX CLAMP BOLT 1
2PDF LASER WARNING LABEL 1
2T9B ROCK SWITCH ASS’Y 1
2UYY CR.RE. PAN HD. ROUND NECK SCREW M5*0.8-16 1
2VMV TORSION SPRING 1
2VND SHAFT SLEEVE 1
2WV9 BLADE 1
34G0 MOTOR ASS’Y 1
34H0 ARM 1
34H2 MOTOR HANDLE (UP) 1
34H3 MOTOR HANDLE (DOWN) 1
34H4 SEGMENT HANDLE 1
34H5 LEVER 1
34H6 CABLE SHIELD 1
34HH LEAD WIRE ASS’Y 1
34KE BUTTON SWITCH 1
34PD LASER ASS’Y 1
34PS PLUG-BUTTON 1
34QU DUST SHIELD 1
34W8 LABEL 1
3537 INSULATE PLATE 1
35FA LABEL 1
35FB TRADEMARK LABEL 1
35Q3 HEX. SOC. SET SCREW M6*1.0-8 1
36Z2 CUSHION 1
3B3F DUST BAG 1
3CK6 CONTROLLER ASS’Y 1
3CMB CR. RE. TRUSS HD. ROUND NECK SCREW M6*1.0-10 1
3CMC CR. RE. TRUSS HD. ROUND NECK SCREW M6*1.0-14 1
REPLACEMENT PARTS LIST - SAW (PART A)
