INSTALLATION INSTRUCTIONS Installation
10MAR06
II4825-1
Page
56 of 72
“Code 39 Full ASCII”
7 Obtain the mode information from the customer.
8 Touch [Code 39 Full ASCII Mode].
9 Use the BAR CODE READER to read
the correct bar code:
• “Code 39 Full ASCII ON”
• “Code 39 Full ASCII OFF”
10 Touch [BACK].
“Automatic Trigger” and “Manual Trigger”
Important
• “Automatic Trigger” indicates that the BAR CODE READER is continually “On”.
• “Manual Trigger” indicates that the BAR CODE READER operates when the TRIGGER is
actuated.
11 Touch [CONFIGURE AUTOMATIC TRIGGER].
To Next Page
