INSTALLATION INSTRUCTIONS Installation
10MAR06
II4825-1
Page
7 of 72
Section 3: Installation
Unpacking the Equipment
1 Check the SHOCK WATCH on the side
of the carton.
2 Is the SHOCK WATCH red?
3 Record any problems that occur during
this installation. Include this information
in the “OUT OF BOX SURVEY” you
provide to the customer.
Caution
Be careful when you cut the STRAPS. The
STRAPS are tight.
4 Cut the 3 STRAPS.
5 Remove:
• 2 CORNER PROTECTORS
• 2 cartons
– ASSEMBLY KIT 1
– ASSEMBLY KIT 2
6 Unpack the 2 cartons.
H194_0116GC
PROTECTORS
2 CORNER
2 cartons
3 STRAPS
H194_0116GCA
SHOCK
WATCH
Yes No
Stop the
installation
procedure and call
the Technical
Support Center
(TSC).
Continue with
Step 3.
To Next Page
