Kodak EASYSHARE C140 Service Manual

SERVICE MANUAL
10 15APR10 – SM8720-1
Figure 1 COVER AYs, BATTERY DOOR AYs and LCD
Item Part No. Description Quantity Notes
1 3F9937 SCREW - PH, TAP, 1.7 x 4.0 Ni
1 7
2 8H2131 COVER AY - front, silver-beige
1 1
8H2138 COVER AY - front, red
1 1
8H2141 COVER AY - front, aqua
1 1
8H2480 COVER AY - front, orange
1 1
8H2984 COVER AY - front, silver, CD14
1 1
3 8H2132 COVER AY - back, silver-beige, C140
1 1
8H2483 COVER AY - back, silver-beige, CD14
1 1
8H2139 COVER AY - back, red, C140
1 1
8H2484 COVER AY - back, red, CD14
1 1
8H2142 COVER AY - back, aqua, C140
1 1
8H2481 COVER AY - back, orange, C140
1 1
8H2985 COVER AY - back, black, CD14
1 1 Installs with the silver 8H2984.
4 8H2041 LCD - AUO, AO24CN02, 6.0 cm (2.36 in.)
1 1
5 2F6924 SCREW - PTP, TAP, 1.7 x 3.5, H = 0.6, black
1 1
6 4F8649 HOLDER - LCD
1 1 See the “LCD” on Page 47.
7 - - - - SOLDER JOINT
1 3 For the LCD HOLDER.
8 8H2144 FILM - protect, LCD
1 1 You can also use 3F9938.
9 3F9936 SPRING - battery door
1 1
10 3F9935 HINGE - battery door
1 1
11 8H2133 DOOR AY - battery, silver-beige
1 1
8H2140 DOOR AY - battery, red
1 1
8H2143 DOOR AY - battery, aqua
1 1
8H2482 DOOR AY - battery, orange
1 1
8H2986 DOOR AY - battery, silver, CD14
1 1 Installs with the silver 8H2984.
12 8H2145 LABEL - power, silver-beige, C140
1 1
8H2485 LABEL - power, silver-beige, CD14
1 1
- - - - 3F9345 STRAP - wrist, black
1 1 • Not visible in the graphic.
• You can also use 3F8616.

Kodak EASYSHARE C140 Specifications

General

Resolution	8.2 Megapixels
Optical Zoom	3x
LCD Screen Size	2.4 inches
Storage Media	SD/SDHC card
Type	Compact
Digital Zoom	5x
Sensor Type	CCD
Image Sensor Size	1/2.5 inch
Video recording	Yes
Battery Type	AA
Shutter Speed	1/1400 sec - 8 sec
Video Resolution	VGA (640 x 480)
ISO Sensitivity	80, 1600
