SERVICE MANUAL
26 15APR10 – SM8720-1
Checkout Procedures
Checking the General Functions of the CAMERA
• Dangerous Voltage
• You must do these procedures before you return the CAMERA to the customer.
Checking the Power
[1] Install RECHARGEABLE BATTERIES that do not have a full charge into the CAMERA.
[2] Energize the CAMERA.
[3] Check that the CAMERA energizes.
[4] If the LCD displays the “Set Date & Time” options:
• select “Cancel”
• wait until the CAMERA completes energizing
[5] De-energize the CAMERA.
[6] Install a MEMORY CARD into the CAMERA.
[7] Energize the CAMERA.
[8] Check the energize sequence:
•LCD:
– displays the “Auto” mode for approximately 4 seconds
– does not display error codes
• LENS moves to the default “Wide” position
Checking the BUTTONS and SWITCHES
[1] Check the following BUTTONS and SWITCHES:
BUTTON/SWITCH Do:
•“Menu”
•4-WAY
•“OK”
• SHUTTER
1. Press the “Menu” BUTTON.
2. Check that the LCD displays options.
3. Press:
• 4-WAY BUTTON up or down to move through the menu
• “OK” BUTTON to select an option
• “OK” BUTTON again to return to the screen before
• “Menu” BUTTON to quit
• “Menu” BUTTON
• SHUTTER BUTTON
4. Check:
• CAMERA quits the menu
• image is captured
• image displays on the LCD
5. Capture one more image.
To Next Page
