Kodak EASYSHARE C140

Illustrated Parts List
SM8720-1 – 15APR10 11
Caution
• Dangerous Voltage
• You must do a discharge of the STROBE CAPACITOR after you remove the FRONT COVER AY.
• For replacement of the MAIN BOARD, you must remove the CCD from the old MAIN BOARD and install the CCD
onto the new MAIN BOARD.
Figure 2 MAIN BOARD and STROBE BOARD AY
P323_1003DC
1
2
3
4
5
6
7
6
8
P323_1003DCA
6
1
2
3
4
5
6
7
8
6
6
