SERVICE MANUAL
34 15APR10 – SM8720-1
MASTER CAMERA - “Calibration of the MASTER CAMERA”
• Dangerous Voltage
• This procedure is only run with a MASTER CAMERA to make the calibration files.
Prerequisites:
[1] Do LENS AY, MAIN BOARD, STROBE BOARD AY - “Shutter Delay” on Page 32 with the MASTER CAMERA.
To Check:
You cannot check this adjustment.
To Adjust:
[1] Do Preparing the “C140 Master Camera” MEMORY CARD on Page 61.
[2] Insert into the MASTER CAMERA:
• BATTERIES with a full charge
• “C140 Master Camera” MEMORY CARD with the “Batch_Lamp” files
The LENS must:
• be placed in the center of the light.
• not touch the screen of the LIGHT BOX.
[3] Place the CAMERA in front of the LIGHT BOX.
[4] Set the LIGHT BOX to:
•LV10.0
• color temperature 4800 K
[5] Energize the CAMERA to execute the test.
[6] If the LCD displays “Set Date & Time”, select “Cancel”.
[7] Select “Master Big Lamp”.
[8] Press the “OK” BUTTON.
[9] When the test is completed, check that the LCD displays:
•“Done”
• “ISO Calibration Success”
[10] De-energize the CAMERA.
Purpose: To set the values for the LIGHT BOX using the MASTER CAMERA.
Do When: Before calibrations of this type of CAMERA.
Specification: No failure messages display.
Special Tools: • Computer with a MEMORY CARD READER/WRITER
• BATTERIES with a full charge
• LIGHT BOX
• MEMORY CARD
To Next Page
