SERVICE MANUAL
40 15APR10 – SM8720-1
LENS AY, MAIN BOARD: CCD - “Run_In_WBP”
Adjustment Specification
Caution
Dangerous Voltage
Prerequisites:
None
To Check:
You cannot check this adjustment.
To Adjust:
[1] Do Preparing the “C140 Run_In_WBP” MEMORY CARD” on Page 63.
[2] Insert into the CAMERA:
BATTERIES with a full charge
“C140 Run_In_WBP” MEMORY CARD
[3] Place the CAMERA in the dark GEN 3 TEST FIXTURE or with the black cloth covering the LENS.
[4] Energize the CAMERA.
[5] If the LCD displays “Set Date & Time”, select “Cancel”.
[6] Check that “Script Loading...” displays on the LCD.
[7] When the test is completed, check that the LCD displays:
green screen
“Calibration Success”
“Take Image OK”
[8] De-energize the CAMERA.
[9] Remove the MEMORY CARD from the CAMERA.
Purpose: To set the values for “White Bad Pixels”.
Do When: After installing a new:
•CCD
LENS AY
MAIN BOARD
Specification: “WBP” < 20,000
The message “Calibration Success” displays on the LCD.
Special Tools: Computer with a MEMORY CARD READER/WRITER
BATTERIES with a full charge
black cloth or dark GEN 3 TEST FIXTURE
MEMORY CARD
