Adjustments
SM8720-1 – 15APR10 41
[10] Did the LCD display a red screen and the failure message “Calibration Fail”?
The CAMERA complies with the specification if the test is successful a minimum of once for 3 times run.
Postrequisites:
None
Yes No
a. Do Step 1
- Step 10 again.
b. If the LCD displayed the failure message again, do Step 2
- Step 10
again, to 3 times total.
c. If the LCD displayed the failure message again, for a total of 3 times, do
a replacement of the CAMERA.
The procedure is complete.
