Kodak EASYSHARE C140 Service Manual

Alphabetical Index
SM8720-1 – 15APR10 15
Section 2: Alphabetical Index
Alphabetical Index
Part No. Description Figure No.
8H2364 CCD 3
8H2137 BOARD - main 2
8H2365 BOARD AY - main, GAR only 2
8H2136 BOARD AY - strobe 2
8H2142 COVER AY - back, aqua, C140 1
8H2985 COVER AY - back, black, CD14 1
8H2481 COVER AY - back, orange, C140 1
8H2139 COVER AY - back, red, C140 1
8H2484 COVER AY - back, red, CD14 1
8H2132 COVER AY - back, silver-beige, C140 1
8H2483 COVER AY - back, silver-beige, CD14 1
8H2141 COVER AY - front, aqua 1
8H2480 COVER AY - front, orange 1
8H2138 COVER AY - front, red 1
8H2984 COVER AY - front, silver, CD14 1
8H2131 COVER AY - front, silver-beige 1
8H2143 DOOR AY - battery, aqua 1
8H2482 DOOR AY - battery, orange 1
8H2140 DOOR AY - battery, red 1
8H2986 DOOR AY - battery, silver, CD14 1
8H2133 DOOR AY - battery, silver-beige 1
8H2144 FILM - protect, LCD 1
8H2366 FILTER - UV-IR cut 3
- - - - FPC 2
8H2135 FRAME AY 3
3F6204 FUSE - 1.25 A, F800 2
3F6205 FUSE - 2.5 A, F600 2
3F9935 HINGE - battery door 1
4F8649 HOLDER - LCD 1
8H2145 LABEL - power, silver-beige, C140 1
8H2485 LABEL - power, silver-beige, CD14 1
8H2041 LCD - AUO, AO24CN02, 6.0 cm (2.36 in.) 1
8H2134 LENS AY - with CCD 3
8H2146 LENS AY - without CCD 3
4F8595 SCREW - PH, TAP, 1.4 x 2.0, black 2
3F9937 SCREW - PH, TAP, 1.7 x 4.0 Ni 1, 3
2F6923 SCREW - PTP, TAP, 1.7 x 2, 3.2 x 0.3, Ni 2
2F6924 SCREW - PTP, TAP, 1.7 x 3.5, H = 0.6, black 1, 2, 3
- - - - SOLDER JOINT 1, 2
3F9936 SPRING - battery door 1
3F9345 STRAP - wrist, black 1
- - - - TAPE - Mylar 2, 3

Kodak EASYSHARE C140 Specifications

General

Resolution	8.2 Megapixels
Optical Zoom	3x
LCD Screen Size	2.4 inches
Storage Media	SD/SDHC card
Type	Compact
Digital Zoom	5x
Sensor Type	CCD
Image Sensor Size	1/2.5 inch
Video recording	Yes
Battery Type	AA
Shutter Speed	1/1400 sec - 8 sec
Video Resolution	VGA (640 x 480)
ISO Sensitivity	80, 1600
