Kodak EASYSHARE C140

SERVICE MANUAL
14 15APR10 – SM8720-1
Figure 3 LENS and FRAME AYs
Item Part No. Description Quantity Notes
1 2F6924 SCREW - PTP, TAP, 1.7 x 3.5, H = 0.6, black
3 1
2 3F9937 SCREW - PH, TAP, 1.7 x 4.0 Ni
3 3 For the LENS AY.
3 8H2134 LENS AY - with CCD
3 1
8H2146 LENS AY - without CCD
3 1
4 8H2364 CCD
3 1 Includes the METAL PLATE.
5 - - - - TAPE - Mylar
3 1 For the LENS MOTOR.
6 8H2135 FRAME AY
3 1
8H2366 FILTER - UV-IR cut
3 1 Not visible in the graphic.
